◆ Huitong Xinda green energy-saving series low-pressure screw air compressor, compared with the ordinary 0.8mpascrew machine to save more than 30% of the electricity, greatly reduce the production cost and carbon emissions 0customers.
◆ Widely used in low pressure and high air volume equipment, is your best choice.Optimum specific power ismaintained in the range of 0.3-0.6mpa exhaust pressure.
Low-pressure screw air compressor series has changed the traditional compressor with high pressure, the compressed air discharged from the compressor is decompressed, and then transmitted to the gas equipment. Low pressure host system, according to the use of pressure, automatically adjust the compression ratio, in the range of 0.3-0.5Mpa exhaust pressure, can maintain the best effect, can achieve more than 30% electricity savings. Low-pressure screw air compressor can be configured according to the user's air pressure, use the least amount of energy to meet the process system process, save a lot of energy, and the manufacturing cost of the product will be considerably improved.Choose our screw air compressor, find the right pressure, and then less than half of the electricity, the gas supply pressure in the process system can still be guaranteed,and achieve energy conservation and emission reduction.
| Model | HL-132G | HL-150G | HL-160G | HL-170G | |
| Air Flow | M³/Min | 32.5 | 38.0 | 40.7 | 44.0 |
| Working Pressure | Mpa | 4-5 | |||
| Compressed series | Single Stage | ||||
| The environment temperature | ﹣5℃-+45℃ | ||||
| Cooling way | Air cooling | ||||
| Exhaust temperature | ℃ | 55℃ | |||
| Noise | dB（A) | 76±2 | 80±2 | ||
| Drive way | Dirict Drive | ||||
| Power supply | V/PH/HZ | 380V/50HZ,220V/60HZ,415V,Custom Voltage | |||
| Rate of work | KW | 132 | 150 | 160 | 170 |
| Starting way | Variable frequency start | ||||
| Dimension(mm) | Length | 2300 | 2850 | ||
| Width | 1600 | 1900 | |||
| Highly | 1900 | 2400 | |||
| Weight | KG | 1550 | 2000 | 2100 | 2300 |
| Outlet pipe diameter | imch/mm | DN65 | DN125 | ||
